Product Details
＋
General Information
Brand
GEDORE TOOLS
Product Type
Torque Wrenches
Packaging
Retail
Country of Origin
Germany
UPC
4002805415504
California Residents
Part Number
7602180
Physical Characteristics
Color
Metallic & Black
Finish
Zinc-Plated & Chrome-Plated
Material
Steel
Length
246 mm
Width
22 mm
Weight
0.27 kg
0.60 lb
Details
Wrench Type
Torque Wrench
Torque Range Nm
10-50 Nm
Torque Accuracy
/- 3%
Size
Drive Connector Rectangular: 9 x 12 mm
Depth Gauge (C.L): 17.5 mm
Distance from Middle of Handgrip to Pivot Point: 194 mm
Distance from Housing to Drive: 31 mm
Depth Gauge (C.L): 17.5 mm
Distance from Middle of Handgrip to Pivot Point: 194 mm
Distance from Housing to Drive: 31 mm
Features
Classified to DIN EN ISO 6789:2003 Type II Class A, with a factory certificate. Working accuracy: /- 3 % tolerance of scale set torque. The specification of the standard ( /- 4 %) is exceeded.
For controlled bi-directional tightening
Sturdy, varnished tubular steel construction, with zinc-plated rectangular cavity
Release system triggers a tactile and audible signal
Operation only with end fittings with standardized depth gauges, otherwise inaccuracies can arise
Depending on the application, access is possible from the front (e.g. open-end fitting) or side (e.g. reversible ratchet and socket)
For controlled bi-directional tightening
Sturdy, varnished tubular steel construction, with zinc-plated rectangular cavity
Release system triggers a tactile and audible signal
Operation only with end fittings with standardized depth gauges, otherwise inaccuracies can arise
Depending on the application, access is possible from the front (e.g. open-end fitting) or side (e.g. reversible ratchet and socket)
