Product Details
＋
General Information
Brand
Greenlee
Part Number
EK6ATILXB
Product Type
Dieless style crimper
Application
6 Ton Crimping
Packaging
Retail
Country of Origin
Germany
UPC
783310085904
California Residents
Proposition 65 Warning
Return Policy
NCNR - Non-Cancellable / Non-Returnable
Physical Characteristics
Length
19.5" (495mm)
Weight
7.38 kg
16.28 lb
Details
Size
Wire: 6 AWG - 500 kcmil Cu, 6 AWG - 400 kcmil Al
Opening: Open Load Head
Opening: Open Load Head
Grip Type
In-Line style with over molded rubber grip
Features
LED display screen communicating system pressure and battery levels as well as tool diagnostics with real-time tool feedback
Bluetooth Communication - Connect with i-Press App to track tool performance
In line tool style is light weight and very easy to control
One trigger controls all tool functions
Cutting head rotates 360
Tools automatically retract when the crimping cycle is complete
Equipped with Double Tap activation profile
Over-molded tacky grip areas make gripping the tool easier and more comfortable
LED work light illuminates dark work areas
Greenlee battery-powered crimping tools use die-electric, bio-degradable oil
Standard: C/US UL Listed
Crimping Force: 12,400 lbs. (55 kN)
Crimping Capacity: 6 AWG - 500 kcmil Cu, 6 AWG - 400 kcmil Al
Connector Type: Color-coded lugs and splices
Bluetooth Communication - Connect with i-Press App to track tool performance
In line tool style is light weight and very easy to control
One trigger controls all tool functions
Cutting head rotates 360
Tools automatically retract when the crimping cycle is complete
Equipped with Double Tap activation profile
Over-molded tacky grip areas make gripping the tool easier and more comfortable
LED work light illuminates dark work areas
Greenlee battery-powered crimping tools use die-electric, bio-degradable oil
Standard: C/US UL Listed
Crimping Force: 12,400 lbs. (55 kN)
Crimping Capacity: 6 AWG - 500 kcmil Cu, 6 AWG - 400 kcmil Al
Connector Type: Color-coded lugs and splices
