Product Details
＋
General Information
Brand
Greenlee
Part Number
T330-138500
Product Type
Contact Voltage Detector
Number of Pieces
5
What's Included
TAG-330 Detector, TAG-AC60 Overhead Suspension Small Hook Probe, TAG-AC120 Overhead Suspension large Hook Probe, TAG-AD100 Overhead 4" Straight Probe, CM-330 Metal Carrying Case
Packaging
Retail
Country of Origin
France
UPC
783310556206
California Residents
Return Policy
NCNR - Non-Cancellable / Non-Returnable
Physical Characteristics
Length
8.3"
Weight
2.27 kg
5.00 lb
Color
Black / Green
Material
ABS
Details
Size
Operating Voltage Range: 138kV to 500kV phase-to-phase
Operating Frequency: 60Hz
Battery: Field replaceable 9V alkaline battery
Battery Life: Approximately 1 year of typical use
Operating Temperature Range: -15F to 110F (-25C to 40C)
Operating Frequency: 60Hz
Battery: Field replaceable 9V alkaline battery
Battery Life: Approximately 1 year of typical use
Operating Temperature Range: -15F to 110F (-25C to 40C)
Features
Uses direct contact probe to quickly test for presence of voltage from 138kV to 500kV line-to-line
Always on and ready to use with no on/off switch
Produces audible beeps and flashing lights to provide voltage indication
Equipped with All-Check self-test system to verify proper operation
Suitable for both overhead and underground applications
Built-in universal spline for attaching hot stick (sold separately)
Always on and ready to use with no on/off switch
Produces audible beeps and flashing lights to provide voltage indication
Equipped with All-Check self-test system to verify proper operation
Suitable for both overhead and underground applications
Built-in universal spline for attaching hot stick (sold separately)
